laboratory cooker and mixer HOSOKAWA/ - TER BRAAK type TBT-L, in stainless steel. YOM 1997

The cooker unit is made of stainless steel and is controlled by a separate control cabinet The closed kettle is double-jacketed for heating with steam and has a feed port on the top as well as a flap with viewing window To empty the machine, a ball valve with handle is mounted on the bottom For the steam connection, a pressure gauge for pressures from 0 to 16 bar is mounted Furthermore, a pressure gauge for vacuum from 0 to -1 bar is mounted, but no vacuum pump is available
Net capacity: approx. 20 litres
Working pressure: approx. 10 bar max.
Test pressure: approx. 13 bar max.
Safety valve: approx. 10.5 bar max.
